Multipole Connector Clips for Modular Fuse Holders is a mechanical connector accessory designed for linking individual modular fuse holder bases into rigid multi-pole assemblies. Used to build multi-pole fuse blocks from single modules across common cylindrical fuse sizes, keeping alignment and spacing consistent on DIN rail.
🔧 Technical Highlights:
- Function: Joins fuse holder bases into multi-pole assemblies
- Compatibility: Modular fuse holders for 10x38, 14x51 and 22x58 cylindrical fuse sizes
- Installation: Fits between adjacent fuse holder modules during assembly
- Use case: Creates 2-, 3- or 4-pole fuse blocks from single-pole bases
✅ Benefits:
- Creates clean, rigid multi-pole fuse blocks without re-engineering the panel layout
- Helps maintain consistent module spacing and alignment
- Supports standardised build methods for repeatable panel assembly
🚀 Applications:
- Building multi-pole fuse holders for three-phase feeders
- Panel standardisation and modular expansion
- Retrofit of existing single-pole fuse holders into multi-pole blocks
Engineered for safe, repeatable fuse mounting in industrial control panels and distribution systems.
FAQs
- Q: Which fuse holder sizes does this fit?
A: It is intended for modular fuse holder systems used with 10x38, 14x51 and 22x58 cylindrical fuse sizes.
- Q: What problem does it solve?
A: It mechanically links adjacent fuse holder bases so you can build rigid multi-pole fuse blocks with aligned operation and consistent spacing.
