Hiquel TUNV 0–10V Signal Generator is a compact analogue output module designed for commissioning, testing, and manual override of 0–10V control signals. It operates from a 24V AC/DC supply and provides a selectable Auto/Manual output for flexible integration.
🔧 Technical Highlights:
- Supply Voltage: 24V AC/DC
- Output Signal: 0–10V DC
- Operating Modes: Auto / Manual selector switch
- Manual Mode: Output generated by onboard potentiometer
- Auto Mode: Passes external 0–10V control signal
- Mounting: Control panel / automation applications
✅ Benefits:
- Ideal for commissioning and maintenance of 0–10V controlled equipment
- Manual override enables engineers to force test outputs safely
- Quick switching between Auto and Manual modes
- Compact and simple to integrate into existing control wiring
- Provides stable and clean analogue output for accurate testing
🚀 Applications:
- HVAC damper and valve actuator testing
- Lighting control systems using 0–10V dimming
- VFD and analogue input testing
- Calibration, simulation, and commissioning tasks
- General industrial automation requiring controlled analogue signals
A reliable commissioning aid that allows engineers to switch instantly between manual testing and automatic 0–10V control.
FAQs
- Q: What is the advantage of the Auto/Manual switch?
A: It lets engineers test equipment using the onboard potentiometer (Manual), then return the system to external control (Auto) without rewiring.
- Q: Can the TUNV be used for permanent installations?
A: Yes, it is suitable for permanent panel use where manual override or test capability is needed.
