2.5mm² 4 WIRE DOUBLE LEVEL KNIFEDISCONNECT IS SPCL

Stock Code: CPDLK2.5(I.S)

Minimum Quantity:

ex VAT (%) VAT n/a
From ex VAT (%) VAT n/a Call Free
Discount:
Price ex VAT (%):
VAT n/a:
Due In Due In
Notify when back in stock

The Connectwell CPDLK2.5(I.S) is a Double-level internally shorted knife disconnect terminal engineered for clean, modular, and space-efficient wiring in industrial panels.

🔧 Technical Highlights:


  • Connections: 4 connections (2 per level)
  •
  • Clamp Type: Push-In Clamp
  •
  • Mounting: 35mm DIN Rail
  •
  • Material: Polyamide 6.6
  •
  • Colour: Grey
  •
  • Operating Temperature: -40°C to +105°C

✅ Benefits:


  • Organised signal, power, or grounding layout
  •
  • Tool-free or screw-secured connections depending on type
  •
  • DIN-rail mountable for fast panel integration

🚀 Applications:


  • Control panel wiring
  •
  • Signal distribution or grounding
  •
  • Automation or diagnostics systems

CPDLK2.5(I.S) supports reliable, professional-grade connections for control, signal, and ground systems.

Wire Size (mm²)0.2 - 2.5mm²
Width5mm
ColourGrey
Terminal TypePush-In Terminals
FunctionFeed Through
Wire Size (AWG)24 - 12AWG
Number of Connections4
Number of Levels2
Current Rating16A (IEC), 14A (UL)
Voltage Rating500V (IEC), 300V (UL)
Special FeaturesInternally shorted & Dissconnect
Type File Name
Data Sheet CPDLK2.5(I.S).pdf
