2.5 mm² FEED THROUGH + GROUND PUSH IN SPRING CLAMP Terminal Block

Stock Code: CPDLG2.5

Minimum Quantity:

ex VAT (%) VAT n/a
From ex VAT (%) VAT n/a Call Free
Discount:
Price ex VAT (%):
VAT n/a:
Due In Due In
Notify when back in stock

The Connectwell CPDLG2.5 is a Double-Level Ground Terminal Block with 4 total connections, featuring a grey housing and green-yellow marking at the bottom level for grounding via DIN rail.

🔧 Technical Highlights:


  • Connections: 4 total (2 per level, bottom level grounded)
  •
  • Clamp Type: Push-In Clamp
  •
  • Mounting: 35mm DIN Rail (EN 60715)
  •
  • Material: Flame-retardant Polyamide 6.6
  •
  • Colour: Grey body with Green-Yellow marking on bottom level cable entry
  •
  • Rated Current: 24 A
  •
  • Rated Voltage: 800 V
  •
  • Operating Temperature: -40°C to +105°C

✅ Benefits:


  • Provides reliable earthing at bottom tier
  •
  • Compact double-level design saves space
  •
  • DIN rail ground connection ensures mechanical and electrical continuity

🚀 Applications:


  • Grounding sensor returns
  •
  • Control panel signal earth

CPDLG2.5 offers dual-level wiring with integrated grounding for efficient panel layouts.

Wire Size (mm²)0.2 - 2.5mm²
Width5mm
ColourGrey
Terminal TypePush-In Terminals
FunctionGround
Wire Size (AWG)24 - 12AWG
Number of Connections4
Number of Levels2
Type File Name
Data Sheet CPDLG2.5.pdf
