The Connectwell CPST1.5/4 is a Single-Level Push-In Sensor Terminal Block with 4 Connections designed to simplify the wiring of 3-wire sensors and actuators. It provides 2 input and 2 output terminals in a compact housing, ideal for signal distribution in modern control panels.
🔧 Technical Highlights:
- Connections: 4 total (single level)
- Clamp Type: Push-In Clamp
- Mounting: 35mm DIN Rail (EN 60715)
- Material: Flame-retardant Polyamide 6.6
- Colour: Grey body with colour-coded cable entry for signal identification
- Rated Current: 17.5 A
- Rated Voltage: 500 V
- Operating Temperature: -40°C to +105°C
✅ Benefits:
- Enables clear and organised sensor/actuator wiring
- Colour-coded cable entry improves installation accuracy
- Tool-free push-in design speeds up field termination
🚀 Applications:
- Sensor signal distribution
- Machine wiring and modular I/O terminals
- Compact industrial control panels
CPST1.5/4 delivers structured, space-efficient connectivity for 3-wire sensor installations.
FAQs
- Q: Are these components compatible with standard DIN rail sizes?
A: Yes. They are designed for IEC/EN DIN rail systems commonly used in control panels.
- Q: Do you offer end accessories such as end stops, markers and partition plates?
A: Yes. Matching accessories are available to complete safe and tidy panel installations.
