True Off Delay Timer, 24Vac/dc, 110Vac, DPCO

Stock Code: TA04

The TA04 is a DIN Rail mounted DPCO True Off Delay Timer / Time Delay Relay from HIQUEL. It has a timing range of 0.1s - 3 mins and can be powered with the following voltages: 24Vac, 24Vdc, 110Vac

Supply Voltage24Vac/dc & 110Vac
Output Relay / ChannelsDPCO
Output Relay Rating5A @ 230V
FunctionTrue Off Delay
Timing Range0.1s - 3 mins
MountingDIN Rail
Size22.5mm
Terminal TypeScrew Terminals
ProtectionIP20
Weight0.1
Type File Name
Data Sheet ta.pdf
