Overview
EE04MH3C 22 mm Monoblock Mushroom Head - Black, Push to Lock, Turn to Release, 1NO+1NC is a black 22 mm monoblock mushroom head (push to lock, turn to release) with an integrated 1NO+1NC contact. The actuator and contacts come in one ready-to-fit body, so there are no separate contact blocks to choose.
Key Features
- Product type: monoblock mushroom head, push to lock, turn to release
- Colour: black
- Contacts: 1NO+1NC
- Panel cutout: 22.5 mm
- Contact rating: 6 A at 230 V AC (AC-15)
- Ingress protection: IP65 front, IP20 terminals
Typical Applications
- Stop and reset circuits on machine control panels
- Operator stations needing a large, easy-to-find actuator
- OEM machinery and automation equipment
- Maintenance and replacement of 22 mm operators
Technical Specification
| Attribute | Details |
|---|
| Brand | Esbee |
| Stock Code | EE04MH3C |
| Product Type | Monoblock mushroom head, push to lock, turn to release |
| Colour | Black |
| Contacts | 1NO+1NC |
| Panel cutout | 22.5 mm |
| Contact rating | 6 A at 230 V AC (AC-15) |
| Ingress protection | IP65 front, IP20 terminals |
Downloads and Support
Refer to the product page downloads for the Esbee datasheet and full technical details. Charter Controls can also help confirm whether EE04MH3C is suitable for a specific control panel, machine or replacement application.
FAQs
What contact arrangement does the Esbee EE04MH3C have?
The Esbee EE04MH3C has one normally open and one normally closed contact (1NO+1NC).
What panel cutout does the Esbee EE04MH3C need?
The Esbee EE04MH3C fits a standard 22.5 mm panel cutout.
What is the contact rating of the Esbee EE04MH3C?
The Esbee EE04MH3C is rated 6 A at 230 V AC (AC-15), with IP65 protection at the front of the panel and IP20 at the terminals.
