Overview
EE04MD2C 22 mm Monoblock Mushroom Head Push Button - Black, Momentary, 1NC is a black 22 mm monoblock mushroom head (momentary) with an integrated 1NC contact. The actuator and contacts come in one ready-to-fit body, so there are no separate contact blocks to choose.
Key Features
- Product type: monoblock mushroom head, momentary
- Colour: black
- Contacts: 1NC
- Panel cutout: 22.5 mm
- Contact rating: 6 A at 230 V AC (AC-15)
- Ingress protection: IP65 front, IP20 terminals
Typical Applications
- Stop and reset circuits on machine control panels
- Operator stations needing a large, easy-to-find actuator
- OEM machinery and automation equipment
- Maintenance and replacement of 22 mm operators
Technical Specification
| Attribute | Details |
|---|
| Brand | Esbee |
| Stock Code | EE04MD2C |
| Product Type | Monoblock mushroom head, momentary |
| Colour | Black |
| Contacts | 1NC |
| Panel cutout | 22.5 mm |
| Contact rating | 6 A at 230 V AC (AC-15) |
| Ingress protection | IP65 front, IP20 terminals |
Downloads and Support
Refer to the product page downloads for the Esbee datasheet and full technical details. Charter Controls can also help confirm whether EE04MD2C is suitable for a specific control panel, machine or replacement application.
FAQs
What contact arrangement does the Esbee EE04MD2C have?
The Esbee EE04MD2C has one normally closed (1NC) contact.
What panel cutout does the Esbee EE04MD2C need?
The Esbee EE04MD2C fits a standard 22.5 mm panel cutout.
What is the contact rating of the Esbee EE04MD2C?
The Esbee EE04MD2C is rated 6 A at 230 V AC (AC-15), with IP65 protection at the front of the panel and IP20 at the terminals.
