Relay with UV/OV & SPP protection, dual outputs, and adjustable ON delay.

Stock Code: MG73BH

Minimum Quantity:

ex VAT (%) VAT n/a
From ex VAT (%) VAT n/a Call Free
Discount:
Price ex VAT (%):
VAT n/a:
Due In Due In
Notify when back in stock

The GIC MG73BH features a selectable ON delay for secure system energising during power-up.

🔧 Technical Highlights:

  • Supply Voltage: 240 VAC
  • ON Delay: Selectable 0.5–15 s
  • OFF Delay: Fixed 5 s
  • Under Voltage Threshold: 55–95%
  • Over Voltage Threshold: 105–125%
  • Monitoring Functions: Phase Loss, Sequence, Asymmetry, UV/OV
  • Output: 2 C/O relays

✅ Benefits:

  • Start-up delay minimises false tripping on unstable supply
  • Comprehensive voltage and phase protections
  • Suitable for motor-heavy loads and automation

🚀 Applications:

  • Motor control centres
  • Industrial HVAC units
  • Critical power infrastructure

MG73BH stabilises power-up conditions for sensitive electrical systems.

Supply Voltage230Vac & 3x400Vac
Output Relay / ChannelsDPCO
Output Relay Rating5A @ 230V
MountingDIN Rail
Size36mm
Connections4 Wire
ProtectionIP20, IP40
Weight0.15
Type File Name
Data Sheet voltagemonitoringrelays.pdf
Technical Drawings 2M TIMER.stp.zip
