AC & DC, Over & Under Voltage Monitoring Relay,, 24Vac, DPCO

Stock Code: ICV.24AC

The ICV 24Vac is a DIN Rail mounted DPCO Single Phase Voltage Monitoring Relay from HIQUEL. It can be powered with the following voltages: 24Vac

Supply Voltage24Vac
Output Relay / ChannelsDPCO
Output Relay Rating6A @ 230V
FunctionDC Over Voltage, AC Under Voltage, DC Under Voltage, AC Over Voltage
Monitoring Range0 - 450V
MountingDIN Rail
Size22.5mm
Terminal TypeScrew Terminals
ProtectionIP20
Weight0.19
Type File Name
Data Sheet icv.pdf
