WECON Technology LX5V-4ADV-BD

The WECON LX5V-4ADV-BD is a versatile BD module designed for advanced automation applications. It features:

• Channels: 4 analog voltage inputs
• Resolution: 12 bits
• Analog input range: -10V to 10V (input resistor 160KΩ)
• Power supply: 5VDC ±10%, 70mA (provided internally by host)
• Dielectric withstand voltage: 500V AC, 1 minute (between all terminals and ground)
• Comprehensive precision: ±0.5% of full scale
• A/D conversion time: One scan cycle
• Supports external load resistance: 160KΩ
• Compatible with LX5V series PLCs

This module is ideal for applications requiring precise analog voltage input control in industrial automation systems.

4 channels voltage input type BD Board(-10-10V)
